When it comes to diamond core drill bits, there are truly several factors that come into play as far as seamless operation is concerned.
Timing is one such factor. You need to know when to turn the bit on, how long you need it to work for, and also importantly, when to replace the diamond core drill bit.
The replacement question is important because when it comes to a diamond core drill bit, anything that affects its operation will affect the results of your drill. So, in this article, we’ll look into when to get a diamond core drill bit replacement and what you need to know about the process.
Before we go into the main issue of replacing a diamond drill bit, let’s understand a major question - how long does a diamond core drill bit last?
As you would imagine, there really isn’t a one-size-fits-all answer to this question. The general lifespan of a diamond core drill bit will depend on several factors, including and especially the material you’re drilling and the technique you use in your drilling process.
On average, you can expect to use a good, high-quality diamond core drill bit for between 80 and 250 holes. This should cover about 100 to 120 linear meters of drilling before you need to think of a diamond core drill bit replacement.
However, there are also some diamond drill bit options that can last up to 400 holes and beyond under the right circumstances. This will mean that you need to cool the bits properly, maintain the right pressure, and work with compatible materials.
To help you make the right estimates, consider the following:
If you’re drilling block or soft concrete, you can expect to use your bit for up to 150 - 300 holes
Bits working with cured concrete should work between 100 and 200 holes
For reinforced concrete, your bit should last between 50 and 100 holes
Expect to use your bit between 40 and 100 holes if you’re drilling hard stone or granite
For asphalt drilling, anything between 100 and 250 holes should be fine
Now that we’ve answered the question of how long does a diamond core drill bit last, let’s take a look at a few critical signs that your diamond core drill bit could be due for a replacement.
There is perhaps no sign of a faulty bit that’s as obvious as a reduction in cutting speed. If you notice that the bit takes longer to break through materials - especially after dressing it - then you most likely have worn-out diamond segments.
If you notice a shiny or polished-looking segment surface, then you most likely have dull diamonds. Or, the diamonds could just have gotten pushed into the metal bond.
You can generally fix this with dressing. But, if you notice that the glazing comes back quickly, a replacement is the best option.
When you see one side of the bit being shorter than the other, it’s a sign that the bit is ready to be replaced. This issue is especially bad because it can lead to additional vibrations, which will affect drilling precision or efficiency.
You could notice chips or cracks in the diamond segments. Any of these is a serious red flag, and it could constitute a safety hazard for you and the tool.
You don’t need to wait for the bit to overheat before you raise an alarm. Even if you notice signs like a burnt smell or dark colors forming, you probably have something to check out.
If heat damage gets to the metal bond, you might not be able to restore the bit’s cutting performance.
A shaky diamond drill bit is a telltale sign of something wrong. If the bit no longer spins well or produces very strong vibrations, it could be a sign of a bent tube or wear in the threads.
Besides the obvious replacement sign, this can also affect the bit’s accuracy and the result of your drill.
As time goes on, you could notice the bit’s outer edge rounding off. The result is that you get smaller, irregular holes that won’t be able to operate optimally.
Periodically, check for cracks or dents on the steel barrel. These, as well as rust signs, can affect the bit’s balance and cause it to fail when it’s under massive load. And as you can imagine, they point to a need to replace the entire thing.
With so much already discussed concerning the lifespan of your diamond core drill bit, it’s important to understand a few factors that can determine how long you can use a bit - and, by extension, when you need to get a diamond core drill bit replacement.
First, you need to consider the composition of the material being drilled and how hard it is.
Under this category, here are a few things to note:
Diamonds tend to wear faster when they come in contact with harder materials like reinforced concrete or granite.
For softer, more abrasive materials, there is also a risk of the metal bond eroding faster.
To manage this, you need to have a specific bond hardness in your bit for each material. A mismatch will reduce the bit’s operational lifespan considerably.
Sometimes, the metal bond that holds the diamonds can also determine how quickly they wear. For instance:
A soft bond will release diamonds much faster, making it better for hard materials.
For soft materials, get a hard bond since it holds the diamonds longer.
If you’re unsure which to use, get high-quality synthetic diamonds that have greater consistency in shape, cut, and size. They cut more efficiently, and they tend to last longer too.
When speed is increased, the diamonds get polished and eventually glaze over. On the other hand, a higher pressure rating can lead to overheating and segment cracks.
The goal here is to maintain a good balance between pressure and speed, so wear is more even.
It’s a common fact that insufficient cooling leads to overheating. But, other effects also include segment damage and a loss of diamonds.
That said, excessive water flow can also wash debris too fast and reduce the efficiency of the bit’s grinding action. So, as it is with speed, balance is key here.
As an operator, you have a responsibility to handle the bit properly. Here are a few things to note:
Let the diamonds work. Keep pressure controlled and steady, and you should be fine
Don’t force the drill bit, and don’t drill at any angle. These only accelerate diamond wear
Remember to maintain and inspect your bit regularly to stop escalating issues
When drill stands aren’t secured properly, you run the risk of vibration and wobbling. Over time, wear develops and you could even lose your segments.
Dressing is a critical step that refreshes your bit. When you don’t do this often, new diamonds aren’t exposed, and glazing accumulates. Soon enough, the entire tool overheats and wears.
In areas with high levels of dust or debris - or sub-optimal temperatures - the bit is unable to cool properly. You’ll also notice that the bits tend to overheat in dry areas if they aren’t managed well.
Although operational wear happens to every drill bit, there are a few tricks you could employ to extend its lifespan a bit longer. Let’s take a look at some of these steps below:
To kick things off, make sure you use the right bit and grit for the material you’re drilling.
Soft-bond bits are better for hard materials
For soft or abrasive materials, hard-bond bits are more ideal
When materials and bits don’t match, wear or glazing becomes inevitable, and a diamond core drill bit replacement becomes necessary.
You also need to ensure that the water flow is steady and adequate. This keeps the bit cool and removes sludge.
Remember - don’t put too much water, and don’t put too little. Overheating is a major risk, but so is excess sludge removal
Also, make sure you’re working with clean water lines and swivels only
As we said earlier, always optimize for pressure and speed. Drill bit manufacturers always have specifications for your bit size and material, so stick with those.
Pressure needs to be moderate and steady, and just let the diamonds cut on their own.
Also, don’t force the drill or work too fast. Both can be detrimental.
Once you notice that cutting slows down or you’re getting shiny segments, dress the bit.
Do this with a soft concrete block or a dressing stone, so you quickly expose new diamonds.
Dressing should be regular so your bit’s efficiency can be maximized.
When it comes to tool alignment, here are a few things to remember:
Make sure your drill stand is firmly mounted and prevent vibration at all costs.
The bit also needs to spin true. You don’t want any movement from one side to the other.
After every use, check the bit for cracks, bent barrels, or sludge buildup. Of course, remember to clean the bit and store it in a dry place where corrosion can’t affect it.
During the dry drilling process, overheating becomes an even greater risk. To mitigate this, work in shorter intervals and regularly turn the bit off so it can cool off.
For the best results, ensure that only trained operators handle your drill bit. Also, remember to read up on the manufacturer’s guidelines and follow them always.
Like every other machine, drill bits easily give you signs when they become overused. And while the replacement process can disrupt your flow, the truth is that you don’t want to overuse a worn bit either. Here’s why
Precision & Timing Become Affected: Using a drill bit even when it’s worn out will reduce your precision. It also means you have to drill for much longer, cutting down on your efficiency significantly
Your Coring Machine Could Get Damaged: A drill bit that needs replacement is pretty bad, but that can be done. If you choose to keep using the bit, you could damage your coring machine entirely - and that isn’t something you can just sort out with a quick fix.
It Constitutes A Safety Hazard: Beyond just the effects on its operational lifespan, using a worn diamond core drill bit also poses a threat to your health. The buildup of smoke and debris isn’t good for you, and excess exposure only worsens the situation.
While they can be sturdy, diamond core drill bits work like every machine and will need to be replaced eventually. Understanding the signs will help you to prepare adequately and put you in the best position to get the most out of your bit.
