| Quantity: | |
|---|---|
ZHONGZHI
For Granite:
Our advantages:
1. There is various of designs available: Ordinary, V type, M type
2. Good sharpness, high production，save production cost，stable quality
Technical Parameters:
Product Name | Suitable for Blades with Diameter(mm) | Suitable for Blades with Core Thickness(mm) | Segment Dimension(mm) | Segment Number |
“V” Shape segment | D900 | 5.5/5.0 | 24*7.0/6.6/6.2*13(15) | 64 |
D1000 | 5.5/5.0 | 24*7.0/6.6/6.2*13(15) | 70 | |
D1200 | 6/5.5 | 24*7.8/7.3/6.8*13(15) | 80 | |
D1350 | 6.5 | 24*8.4/8.0/7.6*13(15) | 88 | |
D1600 | 7.0 | 24*9.4/8.9/8.4*13(15) | 104/108 | |
D1800 | 8.0 | 24*10.0/9.5/9.0*13(15) | 120 | |
D2000 | 8/8.5 | 24*10.6/10.2/9.8*13(15) | 128/132 | |
D2200 | 8.5/9 | 24*11.0/10.5/10.0*13(15) | 132/136 | |
D2500 | 8.5/9 | 24*11.5/11/10.5*13(15) | 140 | |
D3000 | 9/9.5 | 24*12.5/12/11.5*13(15) | 160 | |
D3500 | 9/9.5 | 24*13.5/13/12.5*13(15) | 180 |
For Marble:
Our Advantages:
Good cutting results,smooth and fast cutting, lower power consumption, longer lifespan and stable quality.
Technical Parameters:
Diameter (mm) | Segment Dimension | Segment No. |
L×W×H(mm) | ||
900 | 40*8*12 | 64 |
1000 | 40*8*10 | 70 |
1200 | 24*8*10 | 80 |
1300 | 24*8.5*10 | 88 |
1400 | 24*8.5*10 | 92 |
1600 | 24*9.2*10 | 108 |
1800 | 24*10*10 | 120 |
2000 | 24*10.5*10 | 128 |
2200 | 24*11*10 | 132 |
2500 | 24*12*10 | 140 |
2700 | 24*12*10 | 140 |
3000 | 24*12*12 | 160 |
Application：
Diamond segments welded on circular saw blade for cutting different kinds of marble.
Product Display
EXHIBITION
Certification
Company Introduction
Quanzhou Zhongzhi New Material Technology Co., Ltd. founded in 2003 is a Sino-foreign Joint Venture incorporated company.ZhongZhi has become influential companys in diamond tool industry, we devote ourselves to researching and developing diamond tools in different functions for decades. Under the management conception of “Quality makes achievements, service creates future”, we has formed developing, manufacturing, producing, processing, exportation & service into a coordinate modern enterprise system.
With years of business experience, Zhongzhi brand image has been accepted by more and more customers. For the stable quality and high efficiency, our products help many customers make great achievements. Our excellent after-service allows Zhongzhi and the customers become closer and closer.
